VDI 2230 & EN 1591-1 Software for Bolted Joint Analysis


Bolt Analytics PRO is a post-processing engineering software designed to perform complete bolted joint verification according to VDI 2230 and EN 1591-1.

✔ Full compliance with VDI 2230 and EN 1591-1 Guidelines;
✔ Direct import of FEA results, verify hundreds of bolts in seconds, work faster and save time;
✔ Extended database selection for bolts, washers, materials, coeff. of friction, flanges, gaskets;
✔ Customize flanges, gaskets, materials and bolts with non-standard parameters as you need;
✔ Share Detailed reports with your customers or your team.


In partnership with:


The determination of the correct preload values and tightening torque is influenced by dozens of parameters.
For this reason, torque and preload tables alone are not sufficient for selecting the appropriate values to apply to a specific threaded fastening system, leading to systematic increases in waste, post-sale failures, malfunctions, and customer complaints.

⇾ Thread friction;
⇾ Friction under the nut/bolt head;
⇾ Nut/bolt material;
⇾ Material of the sections forming the joint;
⇾ Friction between contacting sections;
⇾ Bolt length and thickness of the interposed joint;
⇾ Determination of shear forces acting on the joint;
⇾ Tightening factor due to the tightening method used;
⇾ Joint stiffness;
⇾ Fatigue resistance due to dynamic loads;
⇾ Loss or increase of bolt preload based on operating temperature;
⇾ Determination of load losses due to the flattening of surface roughness on the joint material.

These are just some of the parameters that Bolt Analytics PRO analyzes and cross-references during the analysis phase.

1


Solve your static, harmonic, transient or random vibration analysis in your FEM solver.

2


Define geometry of bolt, joint sections, fatigue parameters, temperature variations and much more.

3


Review your results in seconds and verify the reliability of your project.







Complete Bolted Joint Analysis - VDI 2230 Guidelines



Perform a complete verification of the bolted joint according to the VDI 2230 methodology. The software calculates preload ranges, safety factors, stiffness ratios, bolt elongation, joint compression, fatigue resistance and preload variation due to temperature.
FEM data (from your static, harmonic, transient or random vibration analysis) can be imported to reduce modeling effort and increase accuracy.
All calculations follow a traceable and repeatable workflow, suitable for design documentation and technical audits.













EN 1591-1 Analysis for Flanged Joints



Bolt Analytics PRO supports bolted flange and gasketed joint analysis according to EN 1591-1.
The software evaluates bolt load distribution, gasket stress verification and preload variation due to pressure and temperature.
This module is particularly suited for applications in pressure equipment, piping systems and process industry.
The user can setup different scenarios (typically: test condition (I=1), design condition (I=2), operating condition n°1 (I=3), ...) and verify bolt, gasket and flange reliability in one click.
